RY8-230A
The multi-station rotary pre-made bag packaging machine is fully automatic for prefabricated pouches. It completes bag picking, opening, filling, sealing and discharging automatically. Compatible with stand-up, zipper and flat pouches for granules, powder, liquid, paste and solid products. With optional nitrogen flushing, vacuum and coding functions, it serves food, daily chemical, pharmaceutical and hardware industries to raise production efficiency.
RY8-230A
New type automatic rotary pre-made popuch packing machine,featured with stable and high-speed.
Suitable for various shape pre-made pouches,such as stand-up bag,spout bag,zipper
bag ,irregular bag,3-side sealing bag,4-side sealing bag and back sealed bag,etc. With packing,sealing,opening zipper,closing zipper and others functions intergrated .
If configured with different dosing systems,it can achieve the full automatic packing for granule,powder,liquid,and pastes.
Premade Pouch Packing Machine Pouch Styles
The Buena Pack automatic premade pouch packing machine is suitable for pre-made pouches made of laminated, PE or PP packaging film materials. It can handle various shapes such as doy bags, flat and stand-up pouches, spout pouches, zipper pouches, pillow pouches, 3-sided seal, 4-sided seal, and gusset bags.
Spout pouch
Doy Pack
Zipper Bag
4 Sides Sealing Bag
Gusseted Bag
Retort Pouch
Special-Shaped Bags
3 Sides Sealing Bag
JR Series Pouch Packing Machine's Parameter
| Machine Model | RY8-230A |
|---|---|
| Work Process | ①bag feeding ②code printing（optional）③open the bag ④material feeding ⑤material feeding ⑥bag pulling ⑦seal ⑧seal |
| Equipment Material | 304 stainless steel |
| Pneumatic Components | SMC（Japan）/ FESTO（German）（optional)、Airtac（Taiwan）（non-standard parts) |
| Driving Mode | Mechanical drive（cam gear lever full mechanical mode） |
| Heat Sealing | Once, Twice sealing |
| Packing Speed | 30 - 60 bag/min（depending on ingredients） |
| Pouch Type | 3-side sealing bag, Aluminum foil bag, Nylon bag, Compound bag, paper bag,zipper bag, handbag, Triangle bag, etc |
| Pouch Dimension | W：90-230mm L：100 - 380mm |
| Host Power | ≈4.5KW |
| Air Consumption | ≥0.4m³/min |
| Drive Power | 3-phase 5-wire system 380V 50HZ |
| Dimension | 1800 x 1140 x 1460mm（L x W x H）（without elevator） |
| Weight | 1.1Tons |
| Use Of The Environment | Room temperature 10-40℃, 30-90% RH, No Condensation, No Corrosive gas, No dust and other harsh environment. |
Pre-made Bag Packing Machine Structure & Workflow
Pre-made Pouch Packing Machine Process sequence description:
1) Pouch loading and Pouch transferring
Approximately 200 to 300 pieces of empty pouches are supplied to the machine automatically when the operator puts the pouch on the pouch stacker (Pouch Belt Feeder).
Pneumatically operated clamps lift the empty pouch from the feeder and move it to the clamping device on the rotary table.
2) Zip opening and pouch coding
Zip opener opens the zip.
The printer prints the information (Date, Number, etc.) to the specific position of pouches.
3) Pouch opening & detecting open status
With vacuum pad, air nozzle, open blade & sensor, this station opens pouches from both top & bottom. When incorrect open or no pouch is loaded, there will no fill in next filling stations.
4) Products filling
When correct open state is detected, products will fill from dosing system (like cup feeder, combination scales, auger filler….).
5) Spare station
This station can be used for 2nd filling and other purpose usage.
6) Pouch pre-sealing
Constant heat seal bar (0℃ ~ 200℃) seals the pouch mouth. No pouch, no filling, here will no sealing.
7) Pouch sealing
Sealing the pouch with a precious temperature ensure tightly sealed. No pouch, no filling, here will no sealing.
8) Cold sealing, embossing coding and discharge station
Cold sealing bar will press the sealing pattern on the sealing range. Optionally to emboss product information by the stamping mold loaded in sealing bar.
Gripper will release, pouch will discharge to the out feed conveyor.
